152 Configuring System Information
Viewing the Profile Rules Table:
The order in which rules appear in the Profile Rules Table is important. Packets are matched to the first
rule which meets the rule criteria.
1
Open the
Access Profiles
page
.
2
Click
Show All.
The
Profile Rules Table Page
opens:
Figure 6-52. Profile Rules Table Page
Removing a Rule
1
Open the
Access Profiles
page
.
2
Click
Show All
.
The
Profile Rules Table
opens.
3
Select a rule.
4
Select the
Remove
check box.
5
Click
Apply Changes
.
The selected rule is deleted, and the device is updated.
Defining Access Profiles Using CLI Commands
The following table summarizes the equivalent CLI commands for setting fields displayed in the Access
Profiles page.
Table 6-30. Access Profiles CLI Commands
CLI Command Description
management access-list name Defines an access-list for management, and enters the
access-list context for configuration.
permit [ethernet interface-number | vlan vlan-id | port-
channel number] [service service]
Sets port permitting conditions for the management
access list.
