• Instance ID — Defines the MSTP instance. The field range is 0-15.
•
Included VLANs — Maps the selected VLANs to the selected instance. Each VLAN belongs to one
instance.
•
Bridge Priority (0-61440, in steps of 4096) — Specifies the selected spanning tree instance device
priority. The field range is 0-61440
•
Designated Root Bridge ID — Indicates the ID of the bridge with the lowest path cost to the
instance ID.
•
Root Port — Indicates the selected instance’s root port.
•
Root Path Cost — Indicates the selected instance’s path cost.
•
Bridge ID — Indicates the bridge ID of the selected instance.
•
Remaining Hops — Indicates the number of hops remaining to the next destination.
Displaying the MSTP Instance Table
1 Open the MSTP Settings page.
2 Click Show All to open the MSTP Instance Table .
Figure 7-37. MSTP Instance Table
