Configuring Device Information 359
The following table contains the IGMP port and LAG members management settings:
Adding Bridge Multicast Addresses
1 Open the Bridge Multicast Group page.
2 Click Add .
The
Add Bridge Multicast Group page opens:
Figure 7-57. Add Bridge Multicast Group
3 Define the VLAN ID and New Bridge Multicast Address fields.
4 Toggle a port to S to join the port to the selected Multicast group.
5 Toggle a port to F to forbid adding specific Multicast addresses to a specific port.
6 Click Apply Changes .
The bridge Multicast address is assigned to the Multicast group, and the device is updated.
D The port/LAG has joined the Multicast group
dynamically in the Current Row.
S Attaches the port to the Multicast group as
static member in the Static Row.
The port/LAG has joined the Multicast group
statically in the Current Row.
F Forbidden.
Blank The port is not attached to a Multicast group.
