Dell PowerConnect 5424

Configuring Quality of Service 425
Mapping a DSCP value and assigning priority queue:
1 Open the DSCP to Queue page.
2 Select a value in the DSCP In column.
3 Define the Queue fields.
4 Click Apply Changes .
The DSCP is overwritten, and the value is assigned a forwarding queue.
Restoring default values:
1 Open the DSCP to Queue page.
2 Check the Restore Defaults checkbox.
3 Click Apply Changes .
The default values are restored.
Assigning DSCP Values Using the CLI Commands
The following table summarizes the equivalent CLI commands for configuring fields in the DSCP to
Queue page.
The following is an example of the CLI commands:
Table 9-8. DSCP Value to Queue CLI Commands
CLI Command Description
qos map dscp-queue dscp-list
to queue-id
Modifies the DSCP to queue mapping.
Console (config)# qos map dscp-queue 33 40 41 to 1
