Installing the HDD carrier
1 Slide the carrier into the drive bay until it clicks into place.
CAUTION
: Ensure that the latch is open before installing the carrier.
2 Lock the latch.
3 Install the following components:
a HDD bezel
b side cover
4 Follow the procedure in After working inside your computer.
Removing the HDD
1 Follow the procedure in Before working inside your computer.
2 Remove the following:
a side cover
18
Removing and installing components
