3. Connect the fan cable to the system board.
4. Route the following cables through the cable holder and connect to the system board:
• SATA and ODD cables
• USB 3.1 cable
5. Install the:
a) PCIe holder
b) front bezel
c) side cover
6. Follow the procedure in After working inside your computer.
VROC module
Removing the VROC module
Plug-out the VROC module from the system board in the upward direction.
Installing the VROC module
Plug-in the VROC module to the system board.
64
Removing and installing components
