Chassis
This chapter illustrates the multiple chassis views along with the ports and connectors and also explains the FN hot key combinations.
Topics:
• Front view
• Back view
• Internal view
• Major components of your system
Front view
1. 5.25 inch ODD bracket 2. Slim optical disk drive
3. Headset port 4. USB 3.1 Gen 1 Type C
5. USB 3.1 Gen 1 Type C port with PowerShare 6. USB 3.1 Gen 1 ports
7. SD card slot 8. HDD activity LED
9. Power button
