NOTE: The system will not power on without the intrusion switch installed.
Installing the intrusion switch
1 Place the intrusion switch into the slot in the system chassis.
2 Replace the screw and secure the switch to the chassis.
3 Connect the cable to the system board.
4 Install the:
a 5.25 inch ODD bracket
b front bezel
c side cover
5 Follow the procedure in After working inside your computer.
Internal chassis speaker
Removing and installing components
33
