Installing front input and output bezel
1. Hold the input and output(I/O) bezel and ensure that the hooks on the bezel snap into the notches on the system.
2. Press the retention tabs and secure them to the chassis.
3. Install the :
a) front bezel
b) side cover
4. Follow the procedure in After working inside your computer.
Optical Disk Drive
Removing the ODD
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a) side cover
b) front bezel
3. To remove the ODD:
a) Remove the optical drive data cable and optical drive power cable from the ODD.
Removing and installing components
37
