Installing the ODD
1. Place the ODD into the 5.25" ODD bracket.
2. Slide the ODD and lock the latch by a click.
3. Connect the optical drive data cable and optical drive power cable to the ODD.
4. Install the:
a) front bezel
b) side cover
5. Follow the procedure in After working inside your computer
5.25 inch ODD bracket
Removing the 5.25 ODD bracket
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a) side cover
b) front bezel
c) ODD
3. To remove the ODD bracket:
a) Remove the five screws[1,2] that secure the bracket to the chassis.
Removing and installing components
39
