Installing the system fan
1 Align the system fan to its slot on the system board and secure it with the 3 screws.
2 Connect the fan cables to the slot on the system board.
3 Install the:
a 5.25 ODD bracket
b ODD
c front bezel
d air shroud
e side cover
4 Follow the procedure in After working inside your computer.
Fan bracket
Removing the fan from the fan bracket
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a side cover
b system fan
42
Removing and installing components
