Input and output panel bracket
Removing input and output panel bracket
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a) side cover
b) front bezel
c) front input and output bezel
d) 5.25 inch ODD bracket
e) front input and output panel
3. To remove the input and output(I/O) panel bracket:
a) Remove the two screws.
b) Slide the I/O module out of the bracket.
44
Removing and installing components
