Installing front input and output bezel
1 Hold the input and output(I/O) bezel and ensure that the hooks on the bezel snap into the notches on the system.
2 Press the retention tabs and secure them to the chassis.
3 Install the :
a front bezel
b side cover
4 Follow the procedure in After working inside your computer.
Optical Disk Drive
Removing the ODD
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a side cover
b front bezel
3 To remove the ODD:
a Remove the optical drive data cable and optical drive power cable from the ODD.
24
Removing and installing components
