Network specifications
Features Specifications
Integrated
Intel i219 Gigabit Ethernet controllers with Intel Remote Wake UP, PXE and Jumbo frames support
Optional
• Intel i210 10/100/1000 single port PCIe (Gen 1 x 1) gigabit network card.
• Intel X550-T2 10GbE dual port PCIe (Gen 3 x 4) network card
• Aquantia AQN-108 2.5Gbit/5Gbe single port PCIe (Gen 3 x 4) network card.
Card slots
Features
Specifications
Type PCIe Gen 3
Slot configuration
for Xeon W and
Core i9X CPUs
• 2 PCIe x 16
• 1 PCIe x 16 wired as x8
• 1 PCIe x 16 wired as x4
• 1 PCIe x 16 wired as x1
• 1 PCI 32/33
Slot configuration
for Core i7X CPUs
• 1x PCIe x16
• 1x PCIe x8
• 1x PCIe x4
• 1x PCIe x1
• Slot 1 is not active in this configuration.
Storage specifications
Features
Specifications
Externally
Accessible
DVD-ROM; DVD+/-RW 5.25” Bay Options: BD, DVD+/-RW
Internally
Accessible
• M.2 NVMe PCIe SSDs — Up to 4 x 1TB drives on 1 Dell Precision Ultra-Speed Drive Quad x16 cards
• Front Flex Bay M.2 NVMe PCIe SSDs -
• Up to 2x M.2/U.2 drives when Xeon W Series and Core X Cascade Lake CPUs are installed
NOTE: U.2 Optane memory is available with Xeon W Cascade Lake Series CPUs only.
• Up to 1x M.2 drive when Core X Sky Lake Series CPUs are installed
• Up to 6x 2.5” SATA drives
• Up to 5x 3.5” SATA drives
• SAS drives with optional controllers and SED are available only on systems with Xeon W CPUs
External connectors
Features
Specifications
Audio
• Rear—1 x Audio Line in/Microphone
• Rear—1 x Audio Line out
• Front—1 x Universal Audio Jack
Network Rear—1 x RJ45 Network
USB
• Front—4 x USB 3.1 Gen1
88 System specifications
