Dell Precision 5820 Tower D02T

PCIe holder
Removing PCIe holder
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a) side cover
b) expansion card
3. To remove the PCIe holder:
a) Press the PCIe holder securing clip [1] and slide the holder [2] out of the chassis.
Installing the PCIe holder
1. Align and place the PCIe holder to the system chassis.
2. Press the holder back until it clicks to the system.
3. Install the:
a) side cover
4. Follow the procedure in After working inside your computer.
Removing and installing components
57
