9 Power control port 10 PCIE0
11 PCIE1 12 CPU fan port
13 System fan port 14 Coin cell battery
15 FLEX0 thermal sensor 16 FLEX1 thermal sensor
17 24 pin power cable 18 Front panel port
19 Power remote 20 USB 2_INT
21 System fan 0 22 USB 2_ex
23 Front panel USB3.2 port 24 Front panel USB3.1 port
25 SATA 0, 1, 2, 3, 4, 5 and ODD 0, 1 ports 26 VROC_key
NOTE: PCIE0 (Callout 10) is only present/supported on motherboards designed for Xeon W Series Processors.
60 Removing and installing components
