Installing the RAID controller battery
1. Slide and place the RAID controller battery into the RAID battery bracket.
2. Press the RAID controller battery into the bracket to secure with the securing clips.
3. Connect the RAID controller battery cable.
RAID controller battery bracket
Removing the RAID controller battery bracket
1. Follow the procedure in Before working inside your computer.
2. Remove the side cover.
3. Remove the RAID controller battery
4. To remove the RAID controller battery bracket:
a) Lift up the securing tab (1), and slide the RAID controller battery bracket out (2).
Removing and installing components
75
