Disassembly and reassembly
SD card
Removing SD card
1. Follow the procedure in Before working inside your computer.
2. Press in on the SD card to release it from the computer.
3. Remove the SD card from the computer.
Installing SD card
1. Slide the SD card into its slot until it clicks into place.
2. Follow the procedure in After working inside your computer.
Battery cover
Removing the battery cover
1. Follow the procedure in Before working inside your computer.
2. To remove the battery cover:
a) Slide the release latch towards the unlock icon to release the battery cover [1].
b) Slide and lift the battery cover to remove it from the computer [2].
2
Disassembly and reassembly 11
