Installing the battery
1. Slide the battery into its slot until it clicks into place.
2. Install the battery cover.
3. Follow the procedure in After working inside your computer
Hard drive
Removing the hard drive
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a) battery cover
b) battery
3. To remove hard drive:
a) Remove the M3.0x3.0 screws that secure the hard drive to the computer [1].
b) Lift the hard drive latch to release the hard drive [2].
c) Slide and lift the hard drive from the computer [3].
Disassembly and reassembly
13
