5 Install the base cover.
6 Follow the procedure in After working inside your computer.
Coin-cell battery
Removing the coin cell battery
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
3 To remove the coin cell battery:
a Disconnect the coin cell battery cable from the connector on the system board [1].
b Peel the coin cell battery from the system [2].
Removing and installing components
23
