Installing the system fan
1 Align and place the system fan to the slot on the palmrest and keyboard assembly [1].
2 Replace the 2 (M2x3) screws to secure the system fan to the palmrest and keyboard assembly [2].
3 Ax the adhesive tape that secures the WLAN antenna cable to the system fan [3].
4 Connect the system fan cable to the connector on the system board [4].
5 Ax the adhesive tape that secures the system fan cable to the heatsink [5].
Removing and installing components
39
