4 Install the:
a battery
b base cover
5 Follow the procedure in After working inside your computer.
Touchpad
Removing the touchpad
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
3 To remove the touchpad:
a Peel the adhesive tape that secures the speaker cable to the touchpad bracket [1].
b Remove the three (M2x2 Big head) screws that secure the touchpad bracket to the palmrest and keyboard assembly [2].
c Lift the touchpad bracket away from the system [3].
Removing and installing components
59
