Dell Vostro 5481 - Installing the System Board

Installing the system board
1 Place the system board and align the screw holes of the system board to the screw holes on the palmrest and keyboard assembly [1].
2 Replace the four screws to secure the system board to the plamrest and keyboard assembly [2].
