Installing the Input and Output board
1 Align and place the IO board to the slot on the palmrest and keyboard assembly [1].
2 Replace the two (M2x3) screws to secure the IO board to the palmrest and keyboard assembly [2].
3 Connect the IO board cable to the connector on the IO board and close the IO board connector latch [3].
4 Ax the adhesive tape to secure the IO board connector [4].
5 Connect the ngerprint reader cable to the connector on the IO board [5].
