Dell Vostro 5481 - Installing the WLAN Card

Installing the WLAN card
1 Connect the WLAN antenna cables to the connector on the WLAN card [1].
2 Slide the WLAN card at an angle into the WLAN connector on the system board [2].
3 Align the screw hole on the WLAN card bracket with the screw hole on the WLAN card and the system board [3].
4 Replace the single (M2x3) screw to secure the WLAN card bracket to the system board [4].
