Installing the power button with ngerprint reader
1 Align and place the power button with ngerprint reader to the slot on the palmrest and keyboard assembly [1].
2 Replace the two (M2x3) screws to secure the power button with ngerprint reader to the palmrest and keyboard assembly [2].
3 Ax the ngerprint reader cable and the ngerprint reader board to the palmrest and keyboard assembly [3].
54
Removing and installing components
