3 Install the:
a battery
b base cover
4 Follow the procedure in After working inside your computer.
Speaker
Removing the speaker
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
3 To remove the speaker:
a Disconnect the speaker cable from the connector on the system board [1].
b Peel the adhesive tape that secures the speaker cable to the touchpad bracket [2].
c Unroute the speaker cable from the palmrest and keyboard assembly [3].
d Lift the speakers from the system [4].
36
Removing and installing components
