Dell Vostro 5481 - Installing the Solid-State Drive

Installing the solid-state drive
1 To install the M.2 2280 SSD module:
a Align and slide the SSD module to the connector on the system board [1].
b Replace the single (M2x3) screw to secure the SSD module to the palmrest and keyboard assembly [2].
34
Removing and installing components
