Dell Vostro 5481 - WLAN Card; Removing the WLAN Card

3 Install the:
a battery
b base cover
4 Follow the procedure in After working inside your computer.
WLAN card
Removing the WLAN card
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a base cover
b battery
3 To remove the WLAN card:
a Remove the single (M2x3) screw that secures the WLAN card bracket to the system board [1].
b Remove the WLAN card bracket away from the WLAN card [2].
c Disconnect the WLAN antenna cables from the connectors on the WLAN card [3].
d Slide and remove the WLAN card from the connector on the system board [4].
Removing and installing components
25
