Dell Vostro 5481 - Page 63

6 Align and place the touchpad bracket to the slot on the plamrest and keyboard assembly [1].
7 Remove the three (M2x2 Big head) screws to secure the touchpad bracket to the palmrest and keyboard assembly [2].
8 Ax the adhesive tape to secure the speaker cable to the touchpad bracket [3].
Removing and installing components
63
