3.3.4 DI and DO Signal Specified by Users
If the default setting of DI/DO signal cannot satisfy the need, self-set the DI/DO signal will do
and easy. The signal function of DI1 ~ 9 and DO1 ~ 6 is determined by parameter P2-10 ~
P2-17, P2-36 and parameter P2-18 ~ P2-22, P2-37 respectively. Please refer to Chapter 7.2,
which shown as the following table. Enter DI or DO code in the corresponding parameter to
setup DI/DO.
Signal Name Pin No. Parameter Signal Name Pin No. Parameter
DI
DI1-
CN1-9
P2-10
DO
DO1+ CN1-7
P2-18
DI2-
CN1-10
P2-11 DO1- CN1-6
DI3-
CN1-34
P2-12 DO2+ CN1-5
P2-19
DI4-
CN1-8
P2-13 DO2- CN1-4
DI5-
CN1-33
P2-14 DO3+ CN1-3
P2-20
DI6-
CN1-32
P2-15 DO3- CN1-2
DI7-
CN1-31
P2-16 DO4+ CN1-1
P2-21
DI8-
CN1-30
P2-17 DO4- CN1-26
DI9 CN1-12 P2-36 DO5+ CN1-28
P2-22
DO5- CN1-27
DO6+ CN1-16
P2-37
DO6- CN1-15
