7.5 Keypad Operation (1)
Function Description Set up network parameters with the keypad
Network environment
(1) Set IP address to "Static": Set the static IP address to "192.168.1.16", netmask
to "255.255.255.0", and gateway to "192.168.1.1".
(2) Set up IP address via DHCP
 Static
1. Enter the corresponding values into each address with the keypad. Press the "Enter"
key on the keypad to complete the setup.
Keypad address Setting Value Description of Function
09-75 0 Set IP address to "Static"
09-76 192 IP Address 1
09-77 168 IP Address 2
09-78 1 IP Address 3
09-79 16 IP Address 4
09-80 255 Net Mask 1
09-81 255 Net Mask 2
09-82 255 Net Mask 3
09-83 0 Net Mask 4
09-84 192 Gateway 1
09-85 168 Gateway 2
09-86 1 Gateway 3
09-87 1 Gateway 4
2. Enter "2" into the address 09-91 with the keypad and press "Enter" on the keypad to
complete the setup of network parameters.

DHCP
1. Enter "1" into the address 09-75 to set the IP via DHCP, and then enter "2" into the
address 09-91. Press the "Enter" key on the keypad to complete the setup.
