A.9 VFD Data Object (Class Code: 0x300)
A.9.1 Class Attributes & Instance Attributes:
Object class = 0x300
Instance = Parameter Group
Attribute = Parameter Member
Instance & Attributes
Instance Attributes
Access
Rule
Name Data Type Description of Attribute
0x00~0x0B 0x00~0x63 Get / Set
VFD
Parameter.
UDINT,
STRING
VFD group parameter data
0x20 0x00~0x02 Get / Set
VFD
Command
UDINT,
STRING
VFD command Data
0x21 0x00~0x1F Get VFD Status
UDINT,
STRING
VFD status Data
0x22 0x00~0x31 Get VFD Status
UDINT,
STRING
VFD status Data
0x26
0x00~0x01
0x40~0x41
0x60~0x62
0xA0~0xA2
Get
VFD
Command
UDINT,
STRING
VFD command Data
0x60 0x00~0x07 Get/Set
VFD
Command
UDINT,
STRING
VFD command Data
0x61 0x00~0x06 Get VFD Status
UDINT,
STRING
VFD status Data
A.9.2 Services:
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x0E
 
Get_Attribute_Single
Returns the attributes of a
designated element
