1 Introduction
1.1 Introduction to EtherNet/IP Communication
EtherNet/IP is an industrial EtherNet protocol managed by ODVA, Inc. (formerly
Open DeviceNet Vendors Association, Inc.); here, "IP" is the abbreviation for Industrial
Protocol. EtherNet/IP is built on the TCP / IP communication protocol, and it is compatible
with ordinary IT networks; it provides a fast and reliable infrastructure for factory
automation (FA) , building automation (BA) , and process automation (PA) applications.
Delta's EtherNet/IP products cover various control and drive applications, including
programmable logic controllers, AC drives, human-machine interfaces, servers, and
switches.
Peripheral devices for EtherNet/IP communication supported by our VFD products
include the CMM-EIP01 communication card. In addition to supporting the EtherNet/IP
protocol, it is also possible to use the DCISoft program to configure and monitor a VFD via
a web-based interface. It is also possible to use the program in conjunction with a
graphical control software and human-machine interface for remote control and
monitoring. In addition, with the automatic detection features of the MDI / MDI-X, it is not
necessary to use a jumper cable. In the following sections, we will provide a more detailed
description of the CMM-EIP01 communication card.
1.2 Features
 Auto-detects transmission speed: 10 / 100 Mbps
 MDI / MDI-X auto-detection
 Supports EtherNet/IP explicit message
 Supports EtherNet/IP I/O connection (Implicit message)
1.3 Network Functions and Specifications
 EtherNet specifications
Item
Specifications
Interface RJ-45 with Auto MDI / MDIX
Number of ports 1 Port
Communication mode IEEE802.3, IEEE802.3u
Cable Category 5e shielding 100 M
Transmission speed 10 / 100 Mbps Auto-Defect
Communication protocol EtherNet/IP
Service support BOOTP
 Environment specifications
Item Specifications
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Teat (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6)
Operating temperature -10 °C – 50 °C (temperature), 90 % (humidity)
Storage -25 °C – 70 °C (temperature), 95 % (humidity)
Vibration / Shock resistant
International standards
IEC 61800-5-1,IEC 60068-2-6 / IEC 61800-5-1,IEC 60068-2-27
Standards
