VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
57
A.6 Connection Manager Object (Class Code: 0x06)
A.6.1 Instance Code: 0x01
A.6.2 Instance Attributes: None
A.6.3 Services:
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x0E
 
Get_Attribute_Single
Returns the attributes of a
designated element
0x4E

Forward Close Close connection
0x54

Forward Open
Establishes a connection with 511
bytes max.
0x5B

Large_Forward_Open
A.7 TCP / IP Interface Object (Class Code: 0xF5)
A.7.1 Instance Code: 0x01
A.7.2 Instance Attributes:
Attribute
ID
Access Rule Name Data Type Description of Attribute
0x01 Get Status DWORD Interface status
0x02 Get
Configuration
Capability
DWORD Interface capability flags
0x03 Get / Set
Configuration
Control
DWORD Interface control flags
0x04 Get
Path Size,
Path
STRUCT of:
UINT,
Padded EPATH
Path size
Path
0x05 Get / Set
Interface
Configuration
STRUCT of:
UDINT,
UDINT,
UDINT,
UDINT,
UDINT,
STRING
IP Address
Network Mask
Gateway Address
Name Server
Name Server 2
Domain Name
0x06 Get / Set Host Name STRING Host name

Status Instance Attribute
Bits Name Description
0-3
Interface
Configuration
Status
0 = The Interface Configuration attribute has not been configured.
1 = The Interface Configuration attribute contains valid configuration obtained
from BOOTP, DHCP or non-volatile storage.
2 = The IP address member of the Interface Configuration attribute contains
valid configuration, obtained from hardware settings (e.g.: pushwheel,
thumbwheel, etc.)
3-15 = Reserved for future use.
