VFD-MS300/MH300 EtherNet/IP Communication Card CMM-EIP01
CMM-EIP01 Operation Manual
56
A.4 Message Router Object (Class Code: 0x02)
A.4.1 Instance Code: 0x01
A.4.2 Instance Attributes: None
A.4.3 Common Services
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x0E

Get Attribute Single
Returns the attributes of a
designated element
A.5 Assembly Object (Class Code: 0x04)
A.5.1 Instance Code:
I/O Message Connection
Name Function Instance Size Description
Connection 1
Input 0x69 32 words Corresponds to the input buffer register
Output 0x68 32 words Corresponds to the output buffer register
Configuration 0x80 128 words Corresponds to the setup component
Connection 1_
Listen only
Input 0x69 32 words Corresponds to the input buffer register
Output 0xC7 0 words
Configuration 0x80 128 words Corresponds to the setup component
Connection 2
Input 0x65 16 words Corresponds to the input buffer register
Output 0x64 3 words Corresponds to the output buffer register
Configuration 0x66 0 words Corresponds to the setup component
Connection 2_
Listen only
Input 0x65 16 words Corresponds to the input buffer register
Output 0xC7 0 words Corresponds to the output buffer register
Configuration 0x66 0 words Corresponds to the setup component
A.5.2 Instance Attributes:
Attribute ID Access Rule Name Data Type Description of Attribute
0x03 Get / Set Data
ARRAY of
BYTE
Instance Code = 0x64 (Get / Set)
Others Get only
0x04 Get Size UINT Instance Code = 0x65 (Get only)
A.5.3 Common Services:
Service
Code
Implemented for
Service Name Description of Service
Class Instance
0x0E
 
Get Attribute Single
Returns the attributes of a
designated element
0x10

Set Attribute Single Modifies attribute value
