Chapter 4 Parameters|VFD-VL
4-42
Settings Functions Descriptions
9
The 3
rd
, 4
th
acceleration
or deceleration time
selection
between 1st/4th
Accel/decel), it will output
4
th
accel/decel time.
0 1 2
nd
accel./decel. time
1 0 3
rd
accel./decel. time
1 1 4
th
accel./decel. time
If the drive receives STOP command, it will decelerate to stop by
Pr.01-31.
10 EF Input
External fault input terminal and decelerates by Pr.07-28. (EF fault will
be recorded)
11 Reserved
12 Stop output
When this function is enabled, the drive output will stop immediately and
the motor is free run. When this function is disabled, the drive will
accelerate to the frequency setting.
13-14 Reserved
15
Operation speed
command form AUI1
When the source of operation speed command is set to AUI1, ACI and
AUI2 at the same time and two or above terminals are ON, the priority is
AUI1>ACI>AUI2.
When this function is enabled, the source of the frequency will force to
be AUI1.
16
Operation speed
command form ACI
When this function is enabled, the source of the frequency will force to
be ACI.
17
Operation speed
command form AUI2
When this function is enabled, the source of the frequency will force to
be AUI2.
18 Emergency Stop
When this function is enabled, the drive will ramp to stop by Pr.07-28
setting.
19-23 Reserved
24 FWD JOG command
When this function is enabled, the drive will execute forward Jog
command.
25 REV JOG command
When this function is enabled, the drive will execute reverse Jog
command.
26 Reserved
27 ASR1/ASR2 selection
ON: speed will be adjusted by ASR 2 setting.
OFF: speed will be adjusted by ASR 1 setting.
28
Emergency stop (EF1)
(Motor coasts to stop)
When it is ON, the drive will execute emergency stop. (it will have fault
code record)
29-30 Reserved
31 High torque bias When Pr.07-19 is set to 3:
