Appendix B Accessories|VFD-VL
B-38
B.9 AMD-EMI Filter Cross Reference
230V 3-phase Model Filter Model Name 230V 3-phase Model Filter Model Name
VFD055VL23A KMF336A VFD055VL43A KMF318A
VFD075VL23A KMF336A VFD075VL43A KMF325A
VFD110VL23A KMF350A VFD110VL43A KMF325A
VFD150VL23A KMF370A VFD150VL43A KMF336A
VFD185VL23A KMF3100A VFD185VL43A KMF350A
VFD220VL23A KMF3100A VFD220VL43A KMF350A
VFD300VL23A KMF3150A VFD300VL43A KMF370A
VFD370VL23A KMF3150A VFD370VL43A KMF370A
VFD450VL43A KMF3100A
VFD550VL43A KMF3150A
VFD750VL43A KMF3150A
For more detail information of filter, please see http://www.dem-uk.com/jkcm/Home
Installation
All electrical equipment, including AC motor drives, will generate high-frequency/low-frequency
noise and will interfere with peripheral equipment by radiation or conduction when in operation. By
using an EMI filter with correct installation, much interference can be eliminated. It is recommended
to use DELTA EMI filter to have the best interference elimination performance.
We assure that it can comply with following rules when AC motor drive and EMI filter are installed
and wired according to user manual:
EN61000-6-4
EN61800-3: 1996
EN55011 (1991) Class A Group 1
General precaution
1. EMI filter and AC motor drive should be installed on the same metal plate.
2. Please install AC motor drive on footprint EMI filter or install EMI filter as close as possible to
the AC motor drive.
3. Please wire as short as possible.
4. Metal plate should be grounded.
5. The cover of EMI filter and AC motor drive or grounding should be fixed on the metal plate and
the contact area should be as large as possible.
Choose suitable motor cable and precautions
Improper installation and choice of motor cable will affect the performance of EMI filter. Be sure to
observe the following precautions when selecting motor cable.
1. Use the cable with shielding (double shielding is the best).
