B.7 Digital Keypad KPVL-CC01
The digital keypad is the display of VFD-VL series. The following keypad appearance is only for
reference and please see the product for actual appearance.
B.7.1 Description of the Digital Keypad KPVL-CC01
MODE Selection Key
Press this key to view diffe rent
operating valu es
Number Key
Used to enter settings
FWD/REV Direction Key
RUN key
JOG Operation Key
Press this key to execute
the JOG freq uency opera tion
PROG/DATA
Used to enter pro gramming parameters
LED Display
Display frequency, curre nt,
volt age and error, etc.
Status Display
Display of driver status
Part Number
STOP/RESET
Backward key
Parameter Unit Key
En ab l e t h e k ey p a d
it can determine the source of
RUN/STOP
Value Modification Key
Used on the modification
for settings and parameters
Pulse/minus Key
S=Stop
R=Run
F=Fault
EFR EQ. TSE IPO N ETE
ES EEE 0E60.0 H EzE
Display of driv er status
=Forward running
=Reverse running
Display message
Display the setting of message
Display Message Descriptions
EFR EQ. TSE IPO N ETE
ES EEE 0E60.0 H Ez E
Press MODE key
Displays the AC drive Master Frequency
TOU TPU REF.EQ EEEE
ES EEE 0EE 0.0 H Ez E
Press MODE key
Displays the actual output frequency present at terminals U/T1, V/T2, and
W/T3
