Delta VFD-VL Series User Manual

Chapter 4 Parameters|VFD-VL
4-15
4.1.9 Group 8 PM Parameters
Pr. Explanation Settings
Factory
Setting
VF
VFPG
SVC
FOCPG TQCPG
FOCPM
08-00
Motor Auto Tuning 0: No function
1: Only for the unloaded motor, auto measure the angle
between magnetic pole and PG origin (08-09)
2: For PM parameters
3: Auto measure the angle between magnetic pole and PG
origin (08-09)
0
○
08-01 Full-load Current of Motor (40-120%)*00-01 Amps #.##
○
08-02
Rated power of Motor 0.00~655.35 kW #.##
○
08-03
Rated speed of Motor (rpm) 0~65535 1710
○
08-04 Number of Motor Poles 2~96 4
○
08-05 Rs of Motor
0.000~65.535Ω
0.000
○
08-06 Ld of Motor 0.0~6553.5mH 0.0
○
08-07 Lq of Motor 0.0~6553.5mH 0.0
○
08-08
Back Electromotive Force
0.0~6553.5Vrms 0.0
○
08-09 Angle between Magnetic
Pole and PG Origin
0.0-360.0°
360.0
○
08-10 Magnetic Pole Re-
orientation
0: Disable
1: Enable
0
○
