Chapter 3 Operation and Start Up|VFD-VL
3-2
3.1 Operation Method
The factory setting for operation method is set to control terminal. But it is just one of the operation
methods. The operation method can be via communication, control terminals settings or optional
digital keypad KPVL-CC01. Please choose a suitable method depending on application and
operation rule. The operation is usually used as shown in the following table.
Operation Method Frequency Source Operation Command Source
Operate from
communication
Please refer to the communication address 2000H and 2119H settings
in the communication address definition.
Control Terminals-
Operate from
external signal
REV
MI1
MI2
MI3
MI4
MI6
MI5
FW D
MI7
E
NOTE
MI8
COM
+10V
-10V
AUI1/AUI2
E
ACI
ACM
4~20mA
A
*
Factory setting:
SINK Mode
multifunction
terminals
Factory
setting
For ward/STOP
Multi-step 1
Multi-step 2
Multi-step 3
Multi-step 4
No functio n
Digital Signal Common
No function
No function
No fu nction
* Don't apply the mains voltage directly
to above terminals.
Power supply-10V 20mA
Master Frequency
-10 to 10V
Reverse/STOP
(*1)
(*1)
(*1) When JP1
o n the co ntr ol boar d is inser ted , MI8 is di sab le d.
KPVL-CC01
keypad
(Optional)
UP/DOWN key
RUN,
STOP/RESET
key
