Delta VFD-VL Series User Manual

Chapter 4 Parameters|VFD-VL
4-20
4.1.13 Group 12 User-defined Parameters
User-defined Parameters with range from group 00 to 11
: The parameter can be set during operation.
Pr.
Explanation
(Default Function)
Settings
VF
VFPG
SVC
FOCPG TQCPG
FOCPM
12-00
Present Fault Record
0610
○ ○ ○ ○ ○ ○
12-01
Present Fault Time of Motor Operation (min.)
0620
○ ○ ○ ○ ○ ○
12-02
Present Fault Time of Motor Operation (day)
0621
○ ○ ○ ○ ○ ○
12-03
Frequency Command at Present Fault
2120
○ ○ ○ ○ ○ ○
12-04
Output Frequency at Preset Fault
2121
○ ○ ○ ○ ○ ○
12-05
Output Current at Present Fault
2122
○ ○ ○ ○ ○ ○
12-06
Motor Frequency at Present Fault
2123
○ ○ ○ ○ ○ ○
12-07
Output Voltage at Present Fault
2124
○ ○ ○ ○ ○ ○
12-08
DC-Bus Voltage at Present Fault
2125
○ ○ ○ ○ ○ ○
12-09
Output Power at Present Fault
2126
○ ○ ○ ○ ○ ○
12-10
Output Torque at Present Fault
2127
○ ○ ○ ○ ○ ○
12-11
IGBT Temperature of Power Module at Present Fault
2128
○ ○ ○ ○ ○ ○
12-12
Multi-function Terminal Input Status at Present Fault
2129
○ ○ ○ ○ ○ ○
12-13
Multi-function Terminal Output Status at Present Fault
212A
○ ○ ○ ○ ○ ○
12-14
Drive Status at Present Fault
212B
○ ○ ○ ○ ○ ○
12-15
Second Most Recent Fault Record
0611
○ ○ ○ ○ ○ ○
12-16
Second Most Recent Fault Time of Motor Operation (min.)
0622
○ ○ ○ ○ ○ ○
12-17
Second Most Recent Fault Time of Motor Operation (day)
0623
○ ○ ○ ○ ○ ○
12-18
Third Most Recent Fault Record
0612
○ ○ ○ ○ ○ ○
12-19
Third Most Recent Fault Time of Motor Operation (min.)
0624
○ ○ ○ ○ ○ ○
12-20
Third Most Recent Fault Time of Motor Operation (day)
0625
○ ○ ○ ○ ○ ○
12-21
Fourth Most Recent Fault Record
0613
○ ○ ○ ○ ○ ○
12-22
Fourth Most Recent Fault Time of Motor Operation (min.)
0626
○ ○ ○ ○ ○ ○
12-23
Fourth Most Recent Fault Time of Motor Operation (day)
0627
○ ○ ○ ○ ○ ○
12-24
Fifth Most Recent Fault Record
0614
○ ○ ○ ○ ○ ○
12-25
Fifth Most Recent Fault Time of Motor Operation (min.)
0628
○ ○ ○ ○ ○ ○
12-26
Fifth Most Recent Fault Time of Motor Operation (day)
0629
○ ○ ○ ○ ○ ○
12-27
Sixth Most Recent Fault Record
0615
○ ○ ○ ○ ○ ○
12-28
Sixth Most Recent Fault Time of Motor Operation (min.)
062A
○ ○ ○ ○ ○ ○
12-29
Sixth Most Recent Fault Time of Motor Operation (day)
062B
○ ○ ○ ○ ○ ○
12-30
No Factory Setting
12-31
No Factory Setting
