Chapter 3 Operation and Start Up|VFD-VL
3-14
Pr.11-01
Elevator Speed
0.10~4.00 m/s
Pr.11-02
Sheave Diameter
100~2000 mm
Pr.11-03
Mechanical Gear Ratio
1~100
Pr.11-04
Suspension Ratio
0: 1:1
1: 2:1
Pr.11-05
Inertial Ratio
1~300%
Pr.11-14
Motor Current at Accel.
50~200%
Pr.11-15
Elevator Acceleration
0.20~2.00m/s
2
3.3.2.6 Step 6
Trial run
This step is used to trial run after finishing the settings of Step 1 to Step 5 to check if it runs
normally after executing the inspection with the loaded motor. At the same time, please also check
if the operations of multi-function output terminals is normal, such as the action of the brake
release and electromagnetic valve correspond to the host controller.
It needs to check the switch between each step speed, current value, the noise in the
carriage and noise source during operation.
3.3.2.7 Step 7
Elevator tuning
1. Setting Pr. 11-00 to bit 0=1
