Page #120 background imageLoading...
Page #120 background image
Chapter 4 Parameters|VFD-VL
4-61
4.2.5 Group 4 Multi-Step Speed Parameters
04-00
Zero Step Speed Frequency
04-01
1st Step Speed Frequency
04-02
2nd Step Speed Frequency
04-03
3rd Step Speed Frequency
04-04
4th Step Speed Frequency
04-05
5th Step Speed Frequency
04-06
6th Step Speed Frequency
04-07
7th Step Speed Frequency
04-08
8th Step Speed Frequency
04-09
9th Step Speed Frequency
04-10
10th Step Speed Frequency
04-11
11th Step Speed Frequency
04-12
12th Step Speed Frequency
04-13
13th Step Speed Frequency
04-14
14th Step Speed Frequency
04-15
15th Step Speed Frequency
Control
mode
VF VFPG SVC FOCPG FOCPM
Factory setting: 0.00
Settings 0.00 to 400.00 Hz
The Multi-Function Input Terminals (refer to Pr.02-01 to 02-08) are used to select one of the
AC motor drive Multi-step speeds. The speeds (frequencies) are determined by Pr.04-00 to
04-15 as shown above.
