Delta VFD-VL Series User Manual

Chapter 2 Installation and Wiring|VFD-VL
2-11
Frame E
Main circuit terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3,
, +1, +2, -
Models Wire Torque Wire Type
VFD300VL43A
VFD370VL43A
VFD450VL43A
57kgf-cm
(49in-lbf)
VFD300VL23A
VFD370VL23A
VFD550VL43A
VFD750VL43A
4-2 AWG.
(21.2-33.6mm2)
200kgf-cm
(173in-lbf)
Stranded
copper only,
75
o
C
2.4 Control Terminals
1
Sink /NPN Mode
COM
MI1
+2 4V
MI2
MI8
~
So urce Mode
2
COM
MI1
+2 4V
MI2
MI8
~
used with internal power (+24Vdc)
The Position of External Terminals
+10V
MO1
MO2
MI3
MI4
MI7
MI6
COM ACMAUI1
ACI
MCM
MRC
RA
MRA
RC
RB
REV
MI2
FWD
MI1
A
UI2
MI5
MI8
-10V
Sink/Source
mode switch
+E24VDCM
