Chapter 4 Parameters|VFD-VL
4-48
Settings Functions Descriptions
18 Reserved
19
Brake Chopper Output
Error
Active when the brake chopper error is detected.
20 Warning Output
Active when the warning is detected.
21 Over-voltage Warning
Active when the over-voltage is detected.
22
Over-current Stall
Prevention Warning
Active when the over-current stall prevention is detected.
23
Over-voltage Stall
prevention Warning
Active when the over-voltage stall prevention is detected.
24
Operation Mode
Indication
Active when the operation command is controlled by external
terminal. (Pr.00-15
=
1) and PU LED on keypad KPVL-CC01 is
OFF.
25 Forward Command
Active when the operation direction is forward.
26 Reverse Command
Active when the operation direction is reverse.
27
Output when Current >=
Pr.02-33
Active when current is >= Pr.02-33.
28
Output when Current <
Pr.02-33
Active when current is < Pr.02-33.
29
Output when frequency
>= Pr.02-34
Active when frequency is >= Pr.02-34.
30
Output when Frequency
< Pr.02-34
Active when frequency is < Pr.02-34.
31
Power Generation
Direction and Status
Verify
Activate when power generation direction is verified.
32
Power Generation
Direction
Activate when power generation direction is forward run.
33
Zero Speed (actual
output frequency)
Active when the actual output frequency is 0. (the drive should
be at RUN mode)
34
Zero Speed with Stop
(actual output frequency)
Active when the actual output frequency is 0 or Stop. (the
drive should be at RUN mode)
35 Fault output option 1
Active when Pr.06-22 is ON.
36 Fault output option 2
Active when Pr.06-23 is ON.
