Chapter 4 Parameters|VFD-VL
4-103
Content Address Function
Bit 12
1: disable bit 06-11
00B: No function
01B: operated by digital keypad
02B: operated by Pr.00-15 setting
Bit 13~14
03B: change operation source
Bit 15 Reserved
2001H Frequency command
Bit 0 1: EF (external fault) on
Bit 1 1: Reset
Bit 2 1: B.B. ON
2002H
Bit 3-15 Reserved
2100H Fault code: refer to Pr.06-16 to Pr.06-21
00: Stop
01: deceleration
10: Ready for operation
Bit 0-Bit 1
11: operation
Bit 2 1:JOG command
00: FWD command, FWD output
01: FWD command, REV output
10: REV command, FWD output
Bit 3-Bit 4
11: Reserved
Status
monitor Read
only
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
Bit 8
1: Master frequency Controlled by communication
interface
Bit 9 1: Master frequency controlled by analog/external
terminals signal
Bit 10
1: Operation command controlled by
communication interface
Bit 11 1: Parameters have been locked
Bit 12 1: enable to copy parameter from keypad
2119H
Bit 13-15 Reserved
2102H Frequency command (F)
2103H Output frequency (H)
2104H Output current (AXXX.X)
2105H DC-BUS Voltage (UXXX.X)
2106H Output voltage (EXXX.X)
2107H Current step number of Multi-Step Speed Operation
2116H Multi-function display (Pr.00-04)
2120H Frequency command when malfunction
2121H Output frequency when malfunction
2122H Output current when malfunction
2123H Motor frequency when malfunction
2124H Output voltage when malfunction
2125H DC-bus voltage when malfunction
2126H Output power when malfunction
2127H Output torque when malfunction
2128H IGBT Temperature of Power Module at Present Fault
