Playback
1
Press TUNER to switch the input source to “TUNER”.
2
Press SEARCH to select “PTY”.
3
Use ui to call out the desired program type.
4
Use CHANNEL + or CHANNEL –.
PTY search begins automatically.
TP search
TP identifies programs that carry trac announcements.
This allows you to easily find out the latest trac conditions in your area
before leaving home.
Use this function to find RDS stations broadcasting trac programs (TP
stations).
1
Press TUNER to switch the input source to “TUNER”.
2
Press SEARCH to select “TP”.
3
Use CHANNEL + or CHANNEL –.
TP search begins automatically.

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
