2 No video is shown on the TV
Symptom Cause / Solution Page
No picture appears. •Check the connections for all devices.
•Insert connection cables all the way in.
•Check that input connectors and output connectors are not reversely connected.
•Check cables for damage.
•Match the input settings to the input connector of the TV connected to this unit.
•Check that the proper input source is selected.
•Check the video input connector setting.
24,25,27,28,
29
–
–
–
54
35
54
While the menu is being displayed, no
video is shown on the TV.
•When the menu is operated during playback of some 3D video contents or of video at some
computer resolutions (such as VGA), no playback video is shown in the background of the
menu.
–
2 The menu screen is not displayed on the TV
Symptom Cause / Solution Page
The menu screen or status
information screen is not displayed on
the TV.
•The menu screen is only displayed on this unit and a TV connected by HDMI cable. If this unit
is connected to a TV using a dierent video output connector, operate while watching the
display on this unit.
•No status information is displayed for some 3D videos or videos with a computer resolution
such as VGA.
•When a 2D video is converted to a 3D video on the TV, the menu screen or status information
screen is not properly displayed.
–
70
–

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
