Inputs
Perform settings related to input source playback.
You do not have to change the settings to use the unit. Make settings when needed.
Input Assign
This unit has certain input sources such as “CBL/SAT” assigned to audio
and video connectors by default. By making the default connections, you
can simply press an input source select button to play back audio or video
from the connected device with ease.
If you have made connections that are dierent to the default settings,
the digital audio input connectors assigned to each input source can be
changed using these items.
Inputs
Input Assign
Source Level
Input Select
Video Source
OPTICAL 1
OPTICAL 2
Enter ReturnENTER BACK
%
•By default, each item is set as follows.
Input
source
Input
connector
CBL/
SAT
DVD Blu-ray GAME AUX
TV
AUDIO
OPTICAL 1
S
OPTICAL 2
S
2 Set Defaults
The “Input Assign” settings are returned to the default settings.

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
